UFO Style RGB led controller wifi/wifi remote controller

Welcome to use LED WiFi Controller, this controller is designed for low voltage(12V-24V) light, such as 12V LED strip,12V panel
light etc. After installation and settings,your phone (IOS or Android system) can control light directly. The remote control
distance reachs 50 meters indoor and more than 100 meters outdoor

Feature:

(1) Input voltage:DC12V-DC24V ,Power:DC12V:192W;DC24V:384W.
(2) Support both wifi control of iOS products such as iPod, iPad, iPhone, iMac(ios4.3 or above), and Android mobile devices such as Samsung, HTC, Nokia, etc(Andriod 2.3 or above).
(3) This controller is designed for low voltage(12V-24V) light, such as 12V LED strip,12V panel light etc.
(4) Single control by phone or integrated control by router,operating platform:requires Android 2.3.3 or later,IOS 6.0 or later.
(5) Memory function,keep same status as last time after power off.

Specifications

(A) RGB/RGBW,16 million colors, built-in 20 dynamic models,DIY models,music modes
(B) divide into groups function
(C) timing function, automatic turn on/off as your setting time. Set any dynamic models
(D) allocate to router by one key¡±WPS¡±
(E) after connecting router,controller¡¯s wifi signal will be hided automatically to prevent hotlinking
(F) memory function,keep same status as last time after power off
(G) single control by phone or integrated control by router
(H) operating platform:requires Android 2.3.3 or later,IOS 6.0 or later

Data Parameter
Input voltage:DC12V-DC24V
Power:DC12V:192W;DC24V:384W;
Application:common anode,constant voltage light,such as 12V LED strip,12V LED panel light etc
Output currrent:4A*4
Connection:common anode
Input:(wire terminal or DC head )
V+: connect anode of power supply
V-: connect cathode of power supply
Output:
V+:connect anode of lamp
R:connect anode of red color
G:connect anode of green color
B:connect anode of blue color
W:connect anode of white color if you light have this port.

Software User Manual

Android£º
Name£ºMagic UFO -WiFi Controller
Running platform:requires Android 2.3 with wifi function or later
Language:Chinese/English,app shows same language as your system¡¯s in default

IOS£º
Name£ºMagic UFO-WiFi
Running platform:requires ISO 6.0 or later
Language:Chinese/English,app shows same language as your system¡¯s in default
